5 inch Raspberry Pi Touch Screen Display

5 inch Raspberry Pi Touch Screen Display This 5 inch Raspberry Pi Touch Screen Display, has a 800×480 high resolution, touch control. Compatible and direct-connect with any revision of Raspberry Pi (except the Pi 1 model B or Pi Zero, which requires an HDMI cable). It is high quality immersion gold surface plating. Features: Drivers provided (works with your own Raspbian/Ubuntu directly) Backlight can be turned off to lower power consumption High quality immersion gold surface plating. Interface: PIN NO. SYMBOL DESCRIPTION 1, 17 3.3V Power positive (3.3V power input) 2, 4 5V Power positive (5V power input) 3, 5, 7, 8, 10, 11, 12, 13, 15, 16, 18, 24 NC NC 6, 9, 14, 20, 25 GND Ground 19 TP_SI SPI data input of Touch Panel 21 TP_SO SPI data output of Touch Panel 22 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching 23 TP_SCK SPI clock of Touch Panel 26 TP_CS Touch Panel chip selection, low active Documents: 5 inch Raspberry Pi Touch Screen Display Wiki Package Included: 5 inch Raspberry Pi Touch Screen Display HDMI Cable (Black)
