Arduino Uno R3 Board With USB Cable

The Arduino Uno R3 with USB Cable is an open-source microcontroller board based on the ATmega328 chip. Featuring 14 digital input/output pins, 6 analog input pins, an onboard 16 MHz ceramic resonator, a port for USB connection, an onboard DC power jack, an ICSP header, and a microcontroller reset button, it contains everything needed to support the microcontroller. Setting it apart from preceding boards, the Uno utilizes the Atmega16U2 (Atmega8U2 up to version R2) programmed as a USB-to-serial converter, eliminating the need for the FTDI USB-to-serial driver chip.  External power can be supplied through an AC-to-DC adapter or battery. The adapter can be connected to the board’s power jack via a 2.1mm center-positive plug; alternatively, battery leads can be inserted into the Gnd and Vin pin headers of the Power connector. The board supports operation within a voltage range of 6 to 20 volts, with a recommended range of 7V to 12V to ensure stability and prevent damage to the voltage regulator. Key Features:   Microcontroller: ATmega328P. Operating Voltage: 5V. Input Voltage: 7-12V. Digital I/O Pins: 14 (including 6 PWM outputs). Analog Input Pins: 6. DC Current: 40mA. Flash Memory: 32 KB. SRAM: 2 KB. EEPROM: 1 KB. Clock Speed: 16 MHz. Applications:   DIY project prototyping. Developing projects requiring code-based control. Automation system development. Learning AVR programming. Entry-level circuit design. To Learn More Visit our Website For more information:-www.mifraelectronics.com Package Includes: 1 x Arduino Uno R3 with USB Cable
